Technical Specification
Yamaha, PW-ST Syetm, 250wh, 70Nm, 25 km/h
Battery
Yamaha, InTube, 630WHh
Fork
SR Suntour, NEX E25-HL0, Lockout, Steel Spring, 63mm travel, Aluminium steerer tube 1 1/8″ – 1/2″ tapered
Brake (front)
Alhonga, HT474, Hydraulic disk brakes
Tube
Dunlop valve
Clamping Ring
Quick-release, 34.9mm
Shift Lever
Shimano, Deore M4100, Trigger switch
Sprocket
Shimano, CSM4100, 11-42 teeth
Chainring
Steel, 38 teeth
Brake Disc (front)
Alhonga, DXR1806, 180mm
Tyre
Schwalbe, Al Grounder Performance, 60-584, 27.5 x 2.4 inch
Rear Wheel Hub
Alu Nabe, 6-bolt standard
Handlebar
XLC, Topflat, 720mm
.
XLC, ALU, A-Head
Saddle
XLC, Trekking
Pedals
VP, E461, Aluminium with reflector
Rear Light
AXA, Juno Ebike
Carrier
Massload, Systemgepacktrager
Stand
Ursus, Mooi, Rear stand
Display
Yamaha, Side Dwitch, 1.7″ LCD, 7 functions
Frame Family
Haibike, Aluminium 6061, Yamaha InTube 630, HD Interface
Crank Arm
Haibike, Forged, Aluminium
Brake (rear)
Alhonga, HT474, Hydraulic disc brakes
Rim
Schurmann, Yak25, With Eyelets, Double Wall, Aluminium
Rear Derailleur
Shimano, Deore M4120
Bottom Bracket
Integrated in the motor
Chain
KMC, e10S
.
Alhonga, HT474, Aluminium
Brake Disc (Rear)
Alhonga, DXR1806, 180mm
Front Wheel Hub
Alu Hub
Spokes
Sapim, Leader
Grips
XLC, Comfort bo3
Headset
Feimin, A-Head Tapered, Ball bearing, Cane Creek, Viscoset, Aluminium
Seat Post
XLC, Aluminium, Patent, 31.6mm
Headlight
Haibike, Skybeamer 150, 50 lm
Dynamo
Via system battery
Fenders
Eurofender, Temo, Chromplastics SKS
Permitted Total Weight
130kg
.
