Technical Specification
6061 Aluminium Frame
Crankset
Aluminium Alloy Crankset
Wheels
6061 Aluminium Rims
Front Fork
SR SUNTOUR Lockout Fork
Tires
CST Puncture-proof 29″ Tires
Brake
Hydraulic Disc Brakes
Drivetrain
Shimano 10-speed Drivetrain
Bottom Bracket
Integrated with the Bafang M410 Mid-drive Motor
Weight*
Net weight: 27 kg (excluding all accessories)
Full weight: 29 kg (including all accessories)
Permissible Max. Weight: 150 kg
Rear Carrier Max. Load: 25 kg
*All stated weight numbers have a +/- 3%-5% tolerance. Net weight includes the battery but excludes all accessories. Full weight includes the battery and all accessories.
Bafang M410 Mid-drive Motor (250W Power, 80 Nm Max. Torque)
Sensor
Integrated Torque Sensor of the Mid-drive Motor
Controller
Integrated Controller of the Mid-drive Motor
Display
TFT LCD Color Display
Battery
36V, 14Ah Lithium-ion Battery with LG Cells
Lights
StVZO-compliant
Top Speed
25 km/h*
*The motor will stop giving assist at the stated top speed. You can still ride beyond the stated top speed with pure muscle power. This limit is set in accordance with local regulations.
Range
Up to 100 km*
*Actual performance will vary depending on temperature, road conditions, rider’s weight, etc.
Climbing Ability
Suitable for Climbing Slopes*
*The actual performance would depend on the rider’s physical strength.
